MORI SEIKI NT1000SZ MULTI AXIS TURNING/MILLING CENTER

CAPACITY: .MAX WORKPIECE DIAMETER 14.57" .SWING OVER CROSS SLIDE 14.57" .MAXIMUM DISTANCE BETWEEN SPINDLE NOSES 35" .BW-AXIS MAX. SWING 35.04" .MAXIMUM TURNING DIAMETER TOOL SPINDLE 14.57"/TURRET 10.63" .MAXIMUM TURNING LENGTH 16.69" .BAR WORK CAPACITY 2.05" OR 2.56" DEPENDING ON CHUCK CYLINDER TYPE TRAVEL: .X1-AXIS TOOL SPINDLE 14.96" .Y AXIS TOOL SPINDLE 4.13" .Z1 AXIS TOOL SPINDLE 18.11" + 6.1" ATC TRAVEL .B AXIS TOOL SPINDLE +/- 120 DEGREES .X2 AXIS TURRET 2 6.10" .Z2 AXIS TURRET 2 24.01" .BW AXIS 0 DEGREES PROCESS/-25 DEGREES PROCESS/-90 DEGREES RETRACT/ -180 DEGREES LS LOADER/-225 DEGREES WORKPIECE CONVEYOR SPINDLE 1: .SPINDLE SPEED 6,000 RPM .NUMBER OF SPINDLE SPEED RANGES 2 STEP WOUND ROTOR .SPINDLE NOSE JIS A2-5 .THROUGH SPINDLE HOLE DIAMETER 2.4" .MINIMUM SPIDNLE INDEXING ANGLE 0.0001 DEGREES .SPINDLE BEARING INSIDE DIAMTER 3.94" .SPINDLE TORQUE 40%ED/30MIN/CONT N.M 223/172/158 SPINDLE 2: .SPINDLE SPEED 6,000 RPM .NUMBER OF SPINDLE SPEED RANGES 1 .
