AJAX 1300 TON FORGING PRESS NEW 1986

CAPACITY 1300 TONS STROKES PER MIN. 70 STROKE LENGTH 10" RAM FACE 31" X 31" F-B TOP KNOCKOUT STROKE 1 1/4" RAM TO TABLE 30" NOMINAL MECH. STROKE 1 5/8" DIE SEAT 32" X 33" F-B WIDTH BETWEEN COLUMNS L-R 37.5" SIDE WINDOW 22" WIDE FLOOR SPACE L-R 134" X F-B 112" HEIGHT ABOVE FLOOR 192" MOTOR 75 HP 900/1,200 RPM APPROX WEIGHT 148,000 LBS EQUIPPED WITH: AIR CLUTCH AIR BRAKE PRESS NEEDS FLYWHEEL REBUILT BUYER RESOPONSIBLE FOR REMOVAL COST. BEING LIQUIDATED FROM ONGOING PLANT OPERATIONS.
