The Fanuc M10iB/20T robot runs on the RJ3iB Controller, it is a robot designed to run on a Gantry system. Ideal for material handling & machine tending applications.
Robot Specifications:
Axes: 6
Payload: 20kg
H-Reach: 1517mm
Repeatability: ±0.1mm
Robot Mass: 147kg
Structure: Articulated
Mounting: Inverted
Robot Motion Speed:
J1 2.75 m/s
J2 165 °/s (2.88 rad/s)
J3 175 °/s (3.05 rad/s)
J4 350 °/s (6.11 rad/s)
J5 340 °/s (5.93 rad/s)
J6 520 °/s (9.08 rad/s)
Robot Motion Range:
J1 +2.4m° - 32m°
J2 ±300°
J3 ±460°
J4 ±400°
J5 ±280°
J6 ±900°
Applications:
Plasma Cutting Robots
Injection Molding Robots
Machine Loading Robots
Machine Tending Robots
Material Handling Robots
Press Tending Robots
Appliance Automation Robots
