The FANUC M-10iA/10MS is a high speed, short arm robot ideal for many different applications, including material handling, bonding, sealing, packaging, cutting.
Robot Specifications:
Axes: 6
Payload: 10kg
H-Reach: 1101mm
Repeatability: ±0.08mm
Robot Mass: 130kg
Structure: Articulated
Mounting: Floor
Robot Motion Speed:
J1 260 °/s (4.54 rad/s)
J2 280 °/s (4.89 rad/s)
J3 315 °/s (5.5 rad/s)
J4 420 °/s (7.33 rad/s)
J5 420 °/s (7.33 rad/s)
J6 720 °/s (12.57 rad/s)
Robot Motion Range:
J1 +340° - 360°
J2 ±250°
J3 ±441°
J4 ±380°
J5 ±280°
J6 ±720°
Applications:
Material Handling Robots
Packaging Robots
Machine Loading Robots
Machine Tending Robots
Cutting Robots
Bonding / Sealing Robots
Fanuc America Robotics are one of the premiere global robot brands. They build absolutely fantastic products and are by far the number one selling robot brand in the United States. If you allow us to re-register your software with Fanuc you will get 24-7 technical support from their expert staff. We will register the robot in your companies name, so when you reach out to Fanuc for support and provide them with your robots F number they will know who you are, and the robot your calling about.
