The Fanuc R‑2000iC/165R is the advanced rack mounted robot, capable of handling up to 165kg. The Fanuc R2000iC/165R robots comes equipped with the Fanuc R‑30iB controller and has a reach up to 3095mm. The robot is electric servo driven with a +/-0.2mm repeatability. The rack mounted Fanuc R‑2000iC/165R will take your manufacturing process to the next level. This rack-mounted model is ideal for increasing your productivity on shelf installations such as press, CNC machining and other machine tending applications. Its huge work envelope also means that it provides maximum flexibility on loading and unloading operations. As well as adding versatility to the robot, rack mounting also saves you valuable floor space.
PRIMARY APPLICATIONS:
Assembly Robots
Spot Welding Robots
Palletizing Robots
Machine Tending Robots
Material Removal Robots
Part Transfer Robots
Dispensing Robots
ROBOT SPECIFICATIONS:
PAYLOAD 165 kg
REACH 3095 mm
AXES 6
REPEATABILITY 0.2 mm
MASS 1370 kg
STRUCTURE Articulated
MOUNTING Rack/Riser/Floor
ROBOT MOTION SPEED:
J1 115 °/s (2.01 rad/s)
J2 110 °/s (1.92 rad/s)
J3 125 °/s (2.18 rad/s)
J4 180 °/s (3.14 rad/s)
J5 180 °/s (3.14 rad/s)
J6 260 °/s (4.54 rad/s)
ROBOT MOTION RANGE:
J1 ±370°
J2 ±200°
J3 ±375°
J4 ±720°
J5 ±250°
J6 ±720°
Fanuc America Robotics are one of the premiere global robot brands. They build absolutely fantastic products and are by far the number one selling robot brand in the United States. If you allow us to re-register your software with Fanuc you will get 24-7 technical support from their expert staff. We will register the robot in your companies name, so when you reach out to Fanuc for support and provide them with your robots F number they will know who you are, and the robot your calling about.
CALL AN R.A.B. INDUSTRIES, INC REPRESENATIVE (586)752-0090 FOR ALL YOUR ROBOTICS AND AUTOMATION NEEDS. RAB BUYS FANUC ROBOTS, KAWASAKI ROBOTS, ABB ROBOTS, MOTOMAN ROBOTS, KUKA ROBOTS, DENSO ROBOTS, UNIVERSAL ROBOTS AND ROBOT PARTS, ROBOT MRO, CONTROLLERS, CABLES, RVS, TEACH PENDANTS. WE ARE ROBOTIC AUTOMATION BULLS.
