The Fanuc R‑2000iC/165F is an advanced, 6‑axis, multi-purpose robot that can handle a 165 kg payload. The R‑2000iC/165F is a flexible robot, making it ideal for a variety of applications, ranging from spot welding to material handling. It has an incredibly durable thin wrist that delivers excellent cycle times, making it perfect for tight space spot welding. Also, the Fanuc R‑2000iC/165F has been thoughtfully designed to maximize use of work space and be in closer proximity to other robots.
Overall, the diverse Fanuc R‑2000iC/165F comes equipped with the new R‑30iB controller and will be a great addition to your factory. Whatever the application, with its 165 kg capacity this model is a great choice for tasks involving high payloads.
PRIMARY APPLICATIONS:
Spot Welding Robots
Material Handling Robots
Assembly Robots
Dispensing Robots
Material Removal Robots
Pick & Place Robots
Packaging Robots
Palletizing Robots
ROBOT SPECIFICATIONS:
PAYLOAD 165 kg
REACH 2655 mm
AXES 6
REPEATABILITY 0.2 mm
MASS 1090 kg
STRUCTURE Articulated
MOUNTING Floor
ROBOT MOTION SPEED:
J1 130 °/s (2.27 rad/s)
J2 115 °/s (2.01 rad/s)
J3 125 °/s (2.18 rad/s)
J4 180 °/s (3.14 rad/s)
J5 180 °/s (3.14 rad/s)
J6 260 °/s (4.54 rad/s)
ROBOT MOTION RANGE:
J1 ±370°
J2 ±136°
J3 ±312°
J4 ±720°
J5 ±250°
J6 ±720°
